The steel stringer terminates at the floor slab, supported by a steel clip angle. The stair treads consist of concrete fill with welded wire fabric reinforcement placed on a metal pan, which is typical for each tread. The assembly is anchored to the floor slab at the centerline of the stringer. Refer to the stair section or floor plan for additional layout and connection specifications.
