An aluminum storefront door with a sweep bears on an aluminum threshold set in a full bed of mastic and anchored directly to the concrete slab. Scheduled interior flooring meets the exterior concrete slab at a one-half-inch elevation transition beneath the threshold assembly.
1/2" EXTERIOR CONCRETE SLAB SCHEDULED FLOORING OVER CONCRETE SLAB ALUMINUM THRESHOLD SET IN FULL BED MASTIC ANCHORED TO SLAB ALUM STOREFRONT DOOR W/ SWEEP N.T.S A603 7 WINDOW SILL (STOREFRONT)
