Manual swinging doors and gates require a minimum twenty-four-inch latch approach clearance on the pull side, alongside a minimum sixty-inch depth clearance. These clearances ensure adequate accessibility for users approaching the latch side of the door.
LATCH APPROACH – PULL SIDE (j) 24” Min. 60” Min. MANEUVERING CLEARANCES AT MANUAL SWINGING DOORS & GATES
