The roof membrane extends up the vertical wall over a four-inch cant strip and is sealed to the top of the vapor retarder. Reglet and counter flashing are embedded in the wall type per plan with a bead of sealant along the top edge. Metal flashing behind the weather-resistive barrier integrates with WRB tape and an insect screen at the base of the siding over a rainscreen cavity.
ROOF MEMBRANE, LAP UP WALL REGLET AND COUNTER FLASHING SIDING OVER RAINSCREEN PER PLAN BEAD OF SEALANT WRB OVER METAL FLASHING WRB TAPE INSECT SCREEN 4" CANT STRIP WALL TYPE PER PLAN SEAL BASE SHEET TO TOP OF VAPOR RETARDER
