An elevator door jamb and associated hardware attach to a wall assembly whose type is sized per plan. Elevator doors, sill and track, and all associated hardware are provided by the elevator manufacturer with diagrammatic positioning that varies depending on the specific model and manufacturer.
ELEVATOR SILL / TRACK BELOW, & ALL ASSOCIATED HARDWARE BY ELEVATOR MFR ELEVATOR DOORS & ALL ASSOCIATED HARDWARE BY ELEVATOR MFR ELEVATOR JAMB & ALL ASSOCIATED HARDWARE BY ELEVATOR MFR WALL, SEE PLAN FOR TYPE NOTE: ELEVATOR HARDWARE IS DIAGRAMMATIC & MAY VARY DEPENDENT ON ELEVATOR MODEL & MFR
