This isometric detail shows a type A backing track assembly for wall openings framed with double studs sized per plan at a minimum of 16 gauge. A 6-inch 16-gauge unpunched backing track is notched around the vertical studs to provide continuous support. Two number 10 flat head self-tapping metal screws fasten the backing to each stud.
BACKING TRACK - TYPE 'A' DOUBLE STUDS AT SIDES OF OPENING STUD PER PLAN (16 GA. MIN) 6" x 16 GA. UNPUNCHED BACKING NOTCHED AROUND STUDS (2) #10 F.H.S.M.S. @ EACH STUD
