This roof valley detail shows a roofing system membrane applied over a fastened one-quarter-inch pre-primed cover board. Tapered rigid insulation with a two-inch minimum and ten-inch maximum thickness is installed over a vapor barrier and metal deck. A flashing membrane is hot-air welded at the valley centerline and finished with a membrane coverstrip. The entire assembly bears on structural steel roof framing.
FLASHING MEMBRANE, HOT-AIR WELD ROOFING SYSTEM MEMBRANE 1/4" PRE-PRIMED COVER BOARD, FASTENED VAPOR BARRIER MTL. DECK, S.S.D. MEMBRANE COVERSTRIP TAPERED RIGID 2" MIN. & 10" MAX. THICK INSULATION, SEE DET. 1/- ROOF FRAMING S.S.D.
