The steel track splice connects aligned top or bottom tracks using a twenty-four-inch minimum length piece of stud nested inside the track profile. Six number six gauge screws secure each flange on each side of the splice minimum. The steel stud splice joins adjacent wall studs using a twenty-four-inch long piece of track fitted over the stud profile. Six number six gauge screws fasten each flange on each side of the splice minimum.
