A-S8R4J — CORNER PERSPECTIVE AT UPPER INTERMEDIATE LANDINGS

Architectural · A-S8R4J

CORNER PERSPECTIVE AT UPPER INTERMEDIATE LANDINGS

Units: metric
Sheet: A5.12
Discipline: Architectural

Materials

Steel Timber / Wood

Elements

Connections / Plates Railings / Guards Stairs

Text on the drawing

MITERED C-CHANNEL STRINGER STEEL PLATE AND ROD HANGER. SEE STRUCTURAL. SOLID WOOD LANDING BEYOND UPRIGHT, TYP. STEEL TOP PLATE AND WOOD FINISH CAP STEEL HANGER PLATE ATTACHED PER STRUC. MESH PANEL BENT AT CORNER 12 CORNER PERSPECTIVE AT UPPER INTERMEDIATE LANDINGS NOT TO SCALE

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
