This section detail shows a reception desk construction with a countertop supporting a touch screen display. The assembly includes a horizontal counter surface with framing detailed by the manufacturer and dimensional clearances of 4'-0 5/8", 8", and 3 3/4". The supporting base structure has an overall height of 2'-0", divided into lower sections of 1'-0" each, with base offsets of 3" and 2".
2' - 0" 5" 3' - 0" 2 3/8" 6 7/8" 2' - 0" 6" 4' - 0 5/8" 8" 3 3/4" TOUCH SCREEN DISPLAY 1' - 0" 1' - 0" 3" 2" BY MFR.
