An exhaust fan mounts to a prefabricated curb by the manufacturer, secured with number ten sheet metal screws. Roofing is provided by the general contractor and integrated with the curb base. An exhaust duct connects below with a backdraft damper, and mounting conditions for the backdraft damper are to be field verified. The assembly is suitable for round or square applications.
