A structural steel angle concealed inside the partition wall supports a floating shelf projecting ten inches or aligned to adjacent cabinet depth. Plastic laminate is specified on all exposed surfaces with edge band wrapping at open ends. The assembly mounts to a partition type defined per plan at a finished height specified per elevation.
PARTITION TYPE PER PLAN STEEL IN WALL WITH STEEL ANGLE SHELF SUPPORT FINISHED HEIGHT PER ELEVATION PLAM-# ALL EXPOSED SURFACES; EDGE BAND WRAP AT OPEN END TYP 10" OR ALIGNED TO ADJ CAB DEPTH 1' - 5" 1 1/2"
