A-S3555 — Lobby Ceiling Step Detail

Architectural · A-S3555

Lobby Ceiling Step Detail

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A-584
Discipline: Architectural

Materials

EIFS / Plaster / Stucco Gypsum / Drywall Timber / Wood

Elements

Ceilings Entrances Millwork / Casework

Text on the drawing

ARCHITECTURAL TRIM T76 ARCHITECTURAL TRIM T77 ARCHITECTURAL TRIM T72 5/8" PLYWOOD NAILER 1/2" PLYWOOD NAILER 5/8" PLYWOOD NAILER 5/8" GYPSUM BOARD CEILING FRAMING CEILING FRAMING 5/8" GYPSUM BOARD ACOUSTIC PLASTER
