An electrical circuit run details the routing of three number ten copper conductors inside a three-quarter-inch conduit, supplemented by one number ten copper ground wire. The run extends approximately 640 feet with a voltage drop of 1.94 percent. The circuit connects to panel schedule reference HB1-2, 4, 6 and links to equipment tag EF 1A.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
