An interior wall partitions up to an existing window glazing and mullion assembly, sealed with a foam rope seal of two cords at the junction. A twenty-gauge aluminum trim with a factory finish matching the window frames is installed at the wall end, notched at the sill and set in clear sealant with a tight fit against the glazing system.
(E) GLAZING (E) MULLION FIT TIGHT, SET TRIM IN CLEAR SEALANT 20 GA. ALUM. TRIM TO MATCH WINDOW FRAMES (FACTORY FINISH) NOTCH AT SILL (N) INTERIOR WALL FOAM ROPE SEAL - (2) CORDS
