Exterior wall corner assembly at the northeast phase line, featuring cold-formed metal framing with interior and exterior gypsum sheathing. The exterior finish consists of aluminum panels installed with joint seals and backer rods over insulation layers. A property line reference offset is dimensioned relative to the exterior panel face. Dimensions establish the corner configuration and panel joint locations.
12 A 4" 5/8" 3' - 4" 5/8" 2' - 5 3/4" PROPERTY LINE 6" AB-02 INS-04A CFMS FRAMING, SEE PLANS INTERIOR GYPSUM SHEATHING 5/8" EXTERIOR TYPE X GYPSUM SHEATHING AB-01A OR AB-01B INS-01A ALUM PANEL SE-01 AND BACKER ROD SE-01 AB-02 ALUM PANEL
