Architectural · A-RRV72

Mechanical Shaft

Units: imperial
Sheet: A461
Discipline: Architectural

Materials

Concrete

Elements

Floors / Slabs Roof / Floor Openings

Text on the drawing

1S2 MECHANICAL SHAFT SLAB EDGE 8' - 5" FL. OPNG. 4' - 6" 1' - 9" 1' - 6" FL. OPNG. 4' - 6" 6' - 9" 1' - 2" 9" 7' - 6"
