This interior partition detail shows a wall intersection constructed with cold-formed metal stud framing and faced with two layers of five-eighths-inch gypsum board on one side and a single layer of five-eighths-inch gypsum board on the other. Joint tape is applied at the gypsum board transitions and corners per specifications. Three-inch acoustic batt insulation is installed within the stud cavity for sound attenuation.
(2) LAYERS 5/8" GYP BD. SEE SPECIFICATIONS. JOINT TAPE METAL STUD FRAMING; SEE WALL ASSEMBLIES. 3" ACOUSTIC BATT INSULATION; SEE SPECIFICATIONS. 5/8" GYP BD; SEE SPECIFICATION. 5/8" GYP. BD; SEE SPECIFICATION.
