A hollow metal steel door frame sits at the finish floor level over a concrete slab. The assembly is secured using two 3/8-inch KB-TZ expansion bolt anchors per jamb with a minimum 3-inch embedment. A base anchor and frame anchors secure the hollow metal jamb to the adjacent concrete and masonry construction. The door leaf provides a 3/8-inch undercut above the finish floor datum.
HM STEEL DOOR JAMB BEYOND BASE ANCHOR (SCHEDULE BELOW) DOOR UNDERCUT 3/8" DOOR FRAME ANCHORS - REFER TO FRAME ANCHOR SCHEDULE AT CMU WALLS (2) 3/8" KB-TZ EXP BOLT ANCHORS PER JAMB WITH MIN 3" EMBEDMENT FINISH FLOOR 0'-0" TOP OF CONC. 3/8" 5 7/8" NOTES: SEEE DETAIL FOR FRAME ANCHOR SCHEDULE. / 7 A9.21
