A metal stud top track runs parallel to a concrete wall panel with diagonal metal stud wall braces spaced at a maximum of eight feet. Dimensions indicate a maximum eight-foot spacing configuration along the length of the wall. Detail callouts reference connections at the stud brace intersections and the concrete panel anchor points.
8'-0" MAX "A" 8'-0" MAX 8'-0" MAX "A" 8'-0" MAX PLAN VIEW TOP OF WALL BRACING CONCRETE WALL PANEL METAL STUD TOP TRACK / SCHEDULE METAL STUD WALL BRACE / SCHEDULE C A
