A-RKR95 — Plan Detail Room 165

Architectural · A-RKR95

Plan Detail Room 165

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Elements

Facades / Cladding Floors / Slabs Partitions Walls

Text on the drawing

WALL ASSEMBLY RE: FLOOR PLANS 9 ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS EXTERIOR WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY RE: FLOOR PLANS (BOTH SIDES) 9 5/8" 1
