A structural steel beam frames into a concrete column using an embedded steel plate measuring 3/4 inch by 18 inches by 3 feet 0 inches. The embedment plate is secured with eight 3/4-inch diameter by 6-inch long anchor studs spaced at a 12-inch gauge. The concrete column reinforcement is omitted for clarity. A note directs the user to see detail 1 on sheet S6.20 for the shear plate thickness, bolts, and welding requirements.
