A storefront system bears on the finish level slab with a field mold system and a field-applied quarter-inch joint. Sealant is installed at the sill by the window subcontractor to weather-seal the junction. A continuous bentonite waterstop is embedded within the cast-in-place concrete wall assembly, which features typical one-half-inch architectural reveals. Galvanized sheet metal flashing is secured to adjacent surfaces at the neighboring building interface.
CAST IN PLACE WALL GALV. SHEET METAL FLASHING SECURED TO ADJACENT SURFACES NEIGHBORING BLDG STOREFRONT SYSTEM SEALANT BY WINDOW SUBCONTRACTOR FINISH LEVEL SLAB CONTINUOUS BENTONITE WATERSTOP 1/2" REVEAL TYP. 1/2" REVEAL TYP. 1/4" FIELD MOLD SYSTEM
