An exterior glazing system featuring a one-inch insulated glazing panel with low-E coating terminates at a soffit assembly. The soffit is constructed of five-eighths-inch fiberglass mat-faced gypsum board with a textured acrylic finish system over light-gauge metal stud framing. A Fry Reglet FDM-625-100 reveal separates the aluminum brake shape with a matching mullion finish from the adjacent surfaces.
31/4" 11 1 /2" 2 1_ 2 " 1'-0" 1" 2" .090" ALUMINUM BRAKE SHAPE; MATCH MULLION FINISH 5_ 8 " FIBERGLAS MAT FACED GYP. BD. (DENS GLASS OR APPROVED EQUAL) WITH DRYVIT TEXTURE ACRYLIC FINISH SYSTEM (TAFS) ON LIGHT GAUGE METAL STUD FRAMING FRY REGLET FDM-625-100 EXTERIOR GLAZING SYSTEM WITH 1" INSULATED GLAZING PANELS WITH LOW-E COATING; REFER TO EXTERIOR ELEVATIONS FOR MORE INFORMATION. GLASS IN GLAZED CURTAIN WALLS AND GLAZED STOREFRONTS SHALL MEET THE SEISMIC REQUIREMENTS OF ASCE 7, SECTION 13.5.9. TYP.
