An automatic door bottom mechanism is concealed within the bottom of the door panel, which matches the door schedule and sits above the finish floor. The door is hung in a hollow metal frame sized per the door height indicated in the schedule. The concealed automatic drop seal lowers as the door closes to seal against the finish floor.
DOOR HEIGHT AS SCHED HOLLOW METAL FRAME DOOR AS SCHEDULED CONCEALED AUTOMATIC DOOR BOTTOM FINISH FLOOR
