A premanufactured metal coping sits atop treated wood blocking with an underlayment layer placed between the blocking and the underlying steel structure. The coping features a factory-applied finish matching the metal panels and utilizes concealed fasteners at all flashing and trim. A perforated corrugated metal panel screen wall is supported by galvanized structural steel and cold-formed metal framing infill. Neoprene spacers or manufacturer-recommended spacers are placed at attachment points to separate dissimilar metals.
PREMANUFACTURED METAL COPING WITH TREATED BLOCKING AND UNDERLAYMENT BETWEEN BLOCKING AND STEEL STRUCTURE. COPING TO MATCH METAL PANEL FINISH, PROVIDE FACTORY APPLIED FINISH CONCEALED FASTENERS, SHOWN FOR REFERENCE, TO BE PROVIDED WHERE POSSIBLE AT ALL FLASHING AND TRIM PER SPEC PROVIDE NEOPRENE SPACES AT ATTACHMENT TO SEPARATE DISSIMILAR METALS, TYP PERFORATED CORRUGATED METAL PANEL SCREEN WALL ON GALVANIZED STRUCTURAL STEEL (REF. STRUCT) AND COLD FORM METAL FRAMING INFILL. PROVIDE SPACER AS RECOMMENDED BY MFR.. BETWEEN DISSIMILAR MATERIALS.
