A popout window jamb assembly features a painted metal panel cladding with a broken corner constructed over a 1x4 wood lining supported by one-half-inch firring strips. A continuous fluid-applied air and water barrier runs behind the cladding layers. Glazing tape and a 2x2 stop secure the window unit within the framed opening.
MTL1 PANEL A8.22 2 FLUID APPLIED AIR AND WATER BARRIER 1X4 WOOD LINING 1/2" FIRRING STRIP PAINTED METAL PANEL W/ BROKEN CORNER FLUID APPLIED AIR AND WATER BARRIER GLAZING TAPE 2X2 STOP
