A-RDF5Y — Rake Detail

Architectural · A-RDF5Y

Rake Detail

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Cold-formed Steel Composite Metal (misc.)Stainless Steel Steel Stone Timber / Wood

Elements

Facades / Cladding Roofs Trusses Waterproofing / Flashing

Text on the drawing

U1 SLATE SHINGLES SELF-ADHERING SHEET UNDERLAYMENT PLYWOOD ROOF SHEATHING 7/8" HAT CHANNEL 1/2" TREATED PLYWOOD CEMENT FIBER LAP SIDING STAINLESS STEEL METAL FLASHING AND COUNTER FLASHING WITH DRIP EDGE CAULK JOINT U1 9 1/4" X 1" CEMENT FIBER TRIM SHEET WATER BARRIER WOOD TRUSS WOOD TRUSS 2 1/4" SCALE: 3" = 1'-0" A1 /U-201 RAKE DETAIL D5
