A two-and-a-half-inch insulated metal wall panel fastens to a structural girt sized per structural drawings. The panel exterior matches adjacent buildings.
2-1/2" INSULATED METAL WALL PANEL TO MATCH ADJACENT BUILDINGS SEE STRUCT. GIRT
