A hollow metal frame is set into a concrete masonry unit wall and secured with jamb anchors spaced at a maximum of eight inches on center. The hollow metal frame is fully grout-filled and protected with a bituminous coating on the exterior face bearing against the masonry. The masonry is notched as required for hardware provisions and varying conditions. A sealant bead finishes the joint between the frame and the masonry edge on both sides. Partition types dictate varying conditions and dimensions that must be coordinated accordingly.
2" 5/8" 1 15/16" 1 9/16" SEE PARTITION TYPE FOR VARYING CONDITIONS -DIMENSIONS TO BE COORDINATED ACCORDINGLY 08 1113 HM FRAME NOTCH MASONRY AS REQ'D FOR HARDWARE PROVISIONS BITUMINOUS COATING 08 1113 GROUT-FILL HOLLOW METAL FRAME 07 9200 SEALANT 1" 1" VARIES 8" MAX. 08 1113 JAMB ANCHOR
