A prefinished breakdown frame with snap-lock clips attaches to a metal stud framed partition sized per the floor plan, which includes batt insulation in the wall cavity where required. A prefinished aluminum trim piece frames the opening. Smoke and draft seals are installed around the rated opening. A door per the schedule swings within the assembly.
PREFINISHED TA-23 ALUM. TRIM PIECE SMOKE AND DRAFT SEALS PROTECTION AROUND ALL RATED OPENINGS, TYP. (WHERE OCCURS) PREFINISHED BREAKDOWN FRAME W/ SNAP-LOCK CLIPS PER FLOOR PLAN BATT INSULATION IN WALL CAVITY (WHERE OCCURS) METAL STUD FRAMED PARTITION PER FLOOR PLAN DOOR PER SCHEDULE PLAN VIEW
