Zee struts measuring 1 1/2 inches by 1 1/2 inches by 16 gauge are spaced at 2 feet on center with a maximum 10-inch dimension. Two staggered P.A.D. units are installed with a 6-inch minimum dimension. Fasteners match detail C requirements.
10" MAX SAME AS 'C' ZEE STRUT 1 1/2" x 1 1/2" x 16 GA @ 2'-0" OC 1/8 1" FASTEN SAME AS 'C' (2) P.A.D. STAGGERED 10" MAX 6" MIN . OFFSET - CONC BEAM F OFFSET - WF BEAM F
