The W7 window profile connects to a door assembly. The profile features a removable stop and a throat opening dimensioned at plus one inch, with overall dimensions including a 1-1/2 inch width and 5/8 inch offsets. Equal spacing and 1-1/4 inch segments are indicated as required along the frame profile.
1 15/16" EQ 1 1/4" AS REQUIRED 1 1/4" EQ 5/8" 1 1/2" 5/8" THROAT OPENING +1" REMOVABLE STOP 1 15/16" W7 WINDOW (GLASS TO DOOR)
