A fire-rated interior wall assembly intersects a concrete foundation wall at Level 1, 100 feet zero inches. A six and seven-eighths inch composite concrete deck bears adjacent to the wall assembly, which includes a structural brace extending back to the foundation wall. A handrail and stair are positioned beyond the primary section cut. The rated assembly transitions cleanly into the concrete substrate with dedicated framing and gypsum board layers.
LEVEL 1 100'-0" 7 CONC. FOUNDATION WALL - RE: STRUCTURAL HANDRAIL (BEYOND) STAIR (BEYOND) 6 7/8" COMPOSITE CONCRETE DECK INTERIOR WALL ASSEMBLY RE: FLOOR PLANS FIRE-RATED ASSEMBLY RE: FLOOR PLAN BRACE BACK TO FOUNDATION WALL
