A designated smoking area sign is specified for mounting at an outdoor smoking patio at a minimum distance of twenty-five feet from any operable window or door. The sign measures seven inches in height and includes a green smoking prohibition icon with text. Installation requires adhering the sign to the building wall according to the manufacturer's instructions and locating it per the site plan.
