A standard concrete curb and gutter assembly is adjacent to a six-foot wide sidewalk and a variable parkway width ranging from zero to twenty-three feet. The top of curb is referenced with dimensional callouts establishing horizontal spacing from the sidewalk edge. Concrete paving components are identified with reference tags.
