An aluminum bottom rail supports a glazed lite specified per the door schedule. The framing assembly rests above the finished floor, with floor transitions coordinated via finish plans and transition details. The surrounding frame extends beyond the primary section.
GLAZED LITE PER DOOR SCHEDULE ALUMINUM BOTTOM RAIL FLOOR BELOW SEE FINISH PLANS AND FLOOR TRANSITION DETAILS FOR FLOOR TRANSITION FRAME BEYOND
