A vertical joint between concrete panels incorporates a backer rod and sealant system for moisture management. A one-inch weep opening is positioned six inches above the finished grade to facilitate drainage from the wall cavity. The assembly maintains a consistent joint width between adjacent concrete elements to accommodate thermal movement.
Text on the drawing
BACKER ROD AND SEALANT (BETWEEN PANELS) E01 1" WEEP OPENING, 6" ABOVE GRADE
