An exterior wall assembly features eight-inch steel studs filled with three-and-a-half-inch batt insulation and faced with five-eighths-inch gypsum board on the interior. The exterior is covered with one-half-inch exterior sheeting, two-and-a-half-inch rigid insulation, and five-eighths-inch horizontal subgirts. One-and-three-eighths-inch metal panels mount to the exterior using a neutral panel adapter and panel starter track. A three-inch minimum dimension and a three-foot zero-inch maximum panel module govern the layout.
1 3/8" 5/8" 2 1/2" 1/2" 8" 5/8" 1-3/8" METAL PANEL NEUTRAL PANEL ADAPTER PANEL STARTER TRACK 5/8" HORIZONTAL SUBGIRT 2-1/2" RIGID INSULATION 8" STEEL STUD W/ 3-1/2" BATT INSULATION 5/8" GYPSUM BOARD 1/2" 3' - 0" MAXIMUM PANEL MODULE 3" MINIMUM 1/2" 1/2" EXTERIOR SHEATHING
