This assembly details an exterior wall corner constructed with cold-formed metal studs. The corner is finished with exterior sheathing and a metal corner trim piece secured with fasteners. The framing is tied together at the corner using self-drilling screws through the stud flanges and into the sheathing and backing members. The assembly incorporates specific material specifications referenced by MasterFormat codes 07 4213.19.A for the exterior cladding, 05 4000.A for the cold-formed metal framing, and 07 2100.A for the insulation or thermal barrier layer.
