This living wall bracket assembly anchors a vertical metal fin to a concrete curb using a stainless steel anchor bolt and a structural metal angle. A one-half-inch by eight-inch aluminum stiffener bar supports a one-half-inch by five-inch aluminum vertical bar. The connection uses stainless steel recessed fasteners, nylon shoulder washers, and typical nylon washers to secure the elements. A dashed line indicates a one-quarter-inch aluminum round bar positioned above and in front of the assembly.
1 1/2" S.S. METAL FIN S.S. RECESSED FASTENER NYLON SHOLDER WASHER NYLON WASHER TYP. 1/2" X 5" ALUM. VERTICAL BAR, TYP. METAL ANGLE, S.S.D. 1/2" X 8" ALUM. STIFFENER BAR ANCHOR BOLT S.S.D. CONC. CURB, S.S.D. FOR REINFORCEMENT 1/2" 7 1/8" EQ EQ 5 1/4" 1/4" 1/4" DAHSED LINE OF 1/4" ALUM. ROUND BAR ABOVE (FRONT)
