A semi-recessed aluminum fire extinguisher cabinet is installed in the wall assembly at a maximum height of forty-eight inches to the fire extinguisher handle. The installation includes a Larsen's architectural series vertical duo model 2409-6R cabinet with clear acrylic glazing and a white baked enamel finish. Inside the cabinet, a multi-purpose dry chemical fire extinguisher with a UL rating of 4A-80B-C, specifically a Larsen's MP10 with a 546 bracket, is secured with a wall bracket and sign. The installation complies with ANSI A117.1 sections 308 and 309, and locations are determined by the local fire marshal and building department official.
