An 8-inch by 8-inch by 1/2-inch hollow structural section steel column extends up from a base plate secured to a Level P4 concrete column. The top of the guard rail is positioned relative to the structural grid and floor level. Steel connections and base plates are coordinated with structural drawings.
LEVEL P4 CONCRETE COLUMN, SEE STRUCTURAL 05 5000 HSS 8"x8"x1/2" COLUMN, SEE STRUCTURAL 05 5000 BASE PLATE, SEE STRUCTURAL T.O GUARD RAIL
