A safety tieback by exterior building maintenance manufacturer is secured above the roof assembly, with the contractor responsible for determining the actual height required by the final roof insulation thickness. A one-inch stainless steel draw band fastens around the assembly, sealed with sealant against moisture intrusion at penetrations.
1" STAINLESS STEEL DRAW BAND SAFETY TIEBACK (BY EXT BLDG MAINT MFR) CONTRACTOR TO DETERMINE ACTUAL HEIGHT REQUIRED BY FINAL ROOF INSULATION THICKNESS SEALANT *
