A 3x3 by 5/16-inch hollow structural section steel post is anchored by a 3/8-inch thick steel base plate secured with 3/8-inch diameter anchor bolts. The base plate is dimensioned at 4 by 6 inches with edge clearances of 3/4-inch and 1/2-inch, aligned with the face of the stud. The post connects horizontally to continuous 2x3 by 5/16-inch tubing and an L2x3 by 5/16-inch angle. A 5/8-inch CDX plywood substrate overlies the top framing assembly.
4" 6" TS 3x3 x 5/16" 3/8" STEEL BASE PLATE HORIZONTAL TS 2 x 3 x 5/16" CONT. 5/8" "CDX" PLYWOOD SUBSTRATE TS 3x3 x 5/16" HORIZ. TS 2 x 3 x 5/16" STEEL BASE PLATE, ALIGN WITH FACE OF STUD L 2x3 x 5/16" 3/4" 3/4" 1/2" 1/2" 3/8" DIA. ANCHOR BOLTS PLAN ELEVATION 4"
