An insulated metal curb bears on a two-by wood leveling block anchored over a metal deck supported by metal purlins with batt insulation below. The exterior of the curb features one and one-half inches of rigid insulation and a metal counter flashing with a three-inch minimum face. A continuous butyl tape is installed between the standing seam metal roof panel and the metal curb unit. A two-inch by one-quarter-inch neoprene gasket sits beneath the unit base rail supporting the ERV-2 unit.
2" X 1/4" NEOPRENE GASKET METAL DECK S.S.D. METAL PERLIN S.S.D. 3" INSULATED STANDING SEEM ROOFING PANEL 2X WOOD LEVELING BLOCK METAL CURB SEE 7|A8.09 1-1/2" RIGID INSULATION ERV-2 BATT INSULATION METAL CURB, SEE A8.13 METAL COUNTER FLASHING 3" MIN FACE CONT. BUTYL TAPE BETWEEN ROOF PANEL AND METAL CURB UNIT BASE RAIL METAL SEAM, SEE 3|A8.13
