An anodized black aluminum mullion section measuring four inches by two inches or two inches by two inches is installed adjacent to a concrete panel leg sized per structural drawings. Glazing is specified per elevations and specifications. A four-inch dimension spans from the edge of the assembly.
HORIZONTAL/ VERTICAL CONC. PANEL LEG SEE STRUCTURAL DWG. GLAZING, SEE ELEV'S & SPEC. TYP. 4" X 2" OR 2" X 2" ANOD. BLACK ALUM. MULLION SECTION SEE ELEVATIONS 4"
