Head condition of a window installed below an existing concrete masonry unit wall assembly. A new metal lintel with expansion anchor bolts spans the opening and supports the existing masonry above. The window unit is anchored directly beneath the lintel, with lines of the wall extending beyond. The assembly integrates the fenestration with the existing structural wall construction.
