A-QFHTT — Telecommunications Detail

Architectural · A-QFHTT

Telecommunications Detail

Units: imperial
Sheet: RA-T2.1.6
Discipline: Architectural

Materials

EIFS / Plaster / Stucco Steel

Elements

Connections / Plates

Text on the drawing

CAT 6A UTP SINGLE GANG FACEPLATE, KEYSTONE COMP. DOUBLE GANG PLASTER REDUCTION RING INSULATED THROAT COMPRESSION TYPE STEEL CONNECTOR 1"C TO CABLE TRAY (TYP.) 4" SQUARE x 2-1/8" DEEP OUTLET BOX. 8P8C JACK KEYSTONE MODULE

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
