Corner geometry of a curtain wall system relative to the edge of slab. Dimensions establish a 4-1/4 inch dimension to the face of glass, a 3-1/4 inch dimension to the centerline of mullion, and a dimension of 1/2 inch at the dimension point. The angle between the adjoining glazing planes is 161.57 degrees. The distance from the glass to the mullion centerline is 7-1/4 inches. The projection of the exterior fin has a variable range between 3-3/8 inches minimum and 1 foot-0 inches maximum, referencing sheets A364 through A373 for additional fin information.
5 EDGE OF SLAB DIM PT 1 / 2 " OF MULLION OF FIN 1 6 1 . 5 7 ° 3 1 / 4 " CURTAIN WALL 4 1 / 4 " F O G 7 1 / 4 " R E : A 3 6 4 - A 3 7 3 F O R F I N I N F O R M A T I O N 3 3 / 8 " ( M I N ) - 1 ' - 0 " ( M A X )
